About Course

Program Arduino and ESP32 microcontrollers in C++ with the Arduino framework: digital and analog I/O, PWM, timing without blocking, serial debugging and Wi-Fi, all in the free Wokwi simulator.

Build · 6 hours · 4 lessons, a lab, an assessed assignment and a portfolio piece

Who it is for

Learners who understand basic circuits and want to write firmware that reads inputs, controls outputs and connects to a network.

Prerequisites

IOT102 or equivalent knowledge of LEDs, resistors, buttons and Ohm's law.

What you will be able to do

  • Compare Arduino Uno and ESP32 boards and choose one for a given project.
  • Write Arduino-framework sketches that use digital I/O, analog input, PWM and the serial monitor.
  • Replace blocking delay() calls with millis()-based timing to run several tasks at once.
  • Connect a simulated ESP32 to Wi-Fi and report its status reliably, including reconnection.

Lessons

  • Lesson 1 · Inside a microcontroller: Arduino and ESP32
  • Lesson 2 · The Arduino programming model
  • Lesson 3 · Non-blocking code and ESP32 connectivity
  • Lesson 4 · Lab and assignment

Lab: A non-blocking order-ready signal with Wi-Fi status

You program a simulated ESP32 for a coffee counter: a button marks an order as ready, an LED blinks without blocking, a buzzer beeps once and a potentiometer sets LED brightness through PWM. The board connects to the simulator's Wi-Fi network and prints its connection state.

Free tools: Wokwi ESP32 simulator (free); optional Arduino IDE 2 or VS Code with PlatformIO

Assessed assignment

Submit your Wokwi project link and the complete sketch, organized into small functions (for example readButton, updateLed, checkWifi). Include a short table that lists each pin, its mode and its purpose. Explain why your loop never blocks and show serial-monitor evidence of the button, PWM and Wi-Fi reconnection logic working. Close with one paragraph on whether you would use an Arduino Uno or an ESP32 for this product and why.

Criterion Weight What excellent work looks like
Functionality 35% Button, blinking LED, buzzer, PWM brightness and Wi-Fi status all work as specified in the simulator.
Non-blocking design 25% No delay() in the main loop; timing uses millis() and the button responds instantly.
Code quality 25% Code is split into named functions, uses constants for pins and has helpful comments and logs.
Board choice reasoning 15% The Uno versus ESP32 decision is justified with concrete factors such as connectivity, voltage, memory and cost.

Portfolio piece

A clean, commented ESP32 firmware template with non-blocking timing and Wi-Fi reconnection that you can reuse in later projects.

Self-paced, 12-month access. Questions are answered in writing through the student panel. A completion record is issued when you finish the course.

Next step

Continue with IOT104 · Sensors, Actuators and Data Collection · 6 hours · $42.00

Continue to the next course

Prefer the whole program? Program in IoT & Smart Systems · $378.00 (10% less than buying the courses separately)

Show More

What Will You Learn?

  • Compare Arduino Uno and ESP32 boards and choose one for a given project.
  • Write Arduino-framework sketches that use digital I/O, analog input, PWM and the serial monitor.
  • Replace blocking delay() calls with millis()-based timing to run several tasks at once.
  • Connect a simulated ESP32 to Wi-Fi and report its status reliably, including reconnection.

Course Content

IOT103 · Microcontrollers: Arduino and ESP32 (6 h)
Program Arduino and ESP32 microcontrollers in C++ with the Arduino framework: digital and analog I/O, PWM, timing without blocking, serial debugging and Wi-Fi, all in the free Wokwi simulator.

  • Lesson 1 · Inside a microcontroller: Arduino and ESP32
  • Lesson 2 · The Arduino programming model
  • Lesson 3 · Non-blocking code and ESP32 connectivity
  • Lesson 4 · Lab and assignment
  • IOT103 Assessment · Microcontrollers: Arduino and ESP32
